HandiFoam® E84 (HFO)

Low-Pressure Spray Polyurethane Foam (SPF)
Home » Product Lines » HandiFoam® E84 (HFO) Spray Polyurethane Foam (SPF)
HandiFoam E84

We’re redefining spray foam technology with the new and improved HandiFoam E84 Spray Foam Insulation. This low-pressure, two-component system delivers a superior application experience with unmatched sprayability, seamless coverage, and durable performance.

  • Advanced Sprayability for Maximum Efficiency
    • Optimized for Applicators – Smooth and controlled spray pattern for superior yield and less rework
    • Lower Labor Costs – Achieve uniform thickness in fewer passes, minimizing touch-ups
    • Comfortable & Portable – Upgraded handle design on disposable kits for added comfort and durability
  • Extended Workability & Shelf Life
    • Performs Year-Round – Consistent application, no matter the season, when used & applied properly
    • Industry-Leading 24-Month Shelf Life – Improved stability for long-term storage and reliability with the disposable kits
  • Superior Insulation & Air Sealing
    • Seamless, Uniform Coverage – Reduces air leakage completing the building envelope
    • Enhanced Energy Efficiency – Improves indoor air quality and lowers heating & cooling costs
  • Next-Generation Chemistry for a Sustainable Future
    • HFO Blowing Agent – Designed to meet environmental regulations while maintaining premium performance
    • Lower Global Warming Impact – Part of our ongoing commitment to sustainability and innovation

Properly applied HandiFoam® E84 reduces energy consumption, leading many homes or buildings to be certified in their respective energy designation. HandiFoam® E84 is also UL GREENGUARD Gold Certified.

HandiFoam® E84 is available in a variety of disposable and refillable sizes and is dispensed using the patented Handi-Gun® Dispensing Unit.













R Value

Initial:
6.6 at 1" thickness

Aged:
6.1 at 1" thickness
11.7 at 2" thickness
Density

Free Rise:
1.75 lb./ft3 (28 kg/m3)

In Place:
2.11 lbs/ft3 (35.2 kg/m3)
Tack-Free Time 30-60 seconds
Cuttable 2–5 minutes
Fully Cured Time 1 hour
Cell Structure >90% CLOSED cell content
Fire Rating

ASTM E84 Class A at 2" thick

Flame Spread: 5

Smoke Developed: 450
Approvals

GREENGUARD Gold
ICC-ES (file in process)
CCMC #(file in process)
NFPA 286
Shelf Life

6 months - Refill
24 months - Disposable
Warning

 WARNING: CANCER  - www.p65Warnings.ca.gov

Links &
Downloads

Item Number
Description
Size
Dispensing Type
Yield
P12130

HandiFoam E84 (HFO)

II-15
Disposable
15 bdft (1.4 m2)
P12135

HandiFoam E84 (HFO)

II-105
Disposable
105 bdft (9.7 m2)
P12140

HandiFoam E84 (HFO)

II-205
Disposable
205 bdft (19 m2)
P12145

HandiFoam E84 (HFO)

II-605
Disposable
605 bdft (56.2 m2)
P12145W

HandiFoam E84 (HFO)
(Includes 25' GHA)

II-605
Disposable
605 bdft (56.2 m2)
P12146

HandiFoam E84 (HFO)
(Excludes GHA / Cylinders Only)

II-605
Disposable
605 bdft (56.2 m2)
P23000

HandiFoam E84 (HFO)
System 8

8 gallon
Refillable
1,007 bdft (94.3 m2)
P23100

HandiFoam E84 (HFO)
System 17

17 gallon
Refillable
2,001 bdft (186 m2)
P23200

HandiFoam E84 (HFO)
System 27

27 gallon
Refillable
3,378 bdft (314 m2)
P23400

HandiFoam E84 (HFO)
System 60

60 gallon
Refillable
7,783 bdft (723 m2)
P23800

HandiFoam E84 (HFO)
System 120

120 gallon
Refillable
14,113 bdft (1,311 m2)

  • Insulation
    • Commercial & Industrial
      • Asbestos abatement and encapsulation
      • Metal buildings
      • Sealing silos and storage bins
      • Cold storage insulation
      • Insulating storage tanks (gas, industrial, winery, etc.)
      • Sealing the roof/wall juncture
      • Retrofitting windows
      • Industrial piping
      • Sound deadening interior walls
    • OEM
      • Manufactured housing
      • Refrigerated trailers
      • Commercial vehicles
      • Air handler/HVAC
      • Hot tubs
      • Trailers
      • Recreational vehicles
      • Temporary emergency structures
      • Vehicle doors
      • Sealing precast concrete forms
    • Other
      • Insulating and sealing small voids and areas
      • Pipe pillows / pipe support
      • Foam shape creation
      • Post installation void filling (ie. hollow stadium seats)
      • Theater set design
      • Swimming pool construction
      • Statue repair
      • Statue creation
      • Taxidermy
      • Repairing and sealing damaged cargo containers
      • Insulating military tents
      • Filling post/pole holes
      • Temporary seal of hopper cans
      • "Tree surgery"
    • Residential
      • Air sealing attic
      • Bath tub insulation and leveling
      • Sealing insulation board joints
      • Foundation insulating
      • Residential wall insulation
      • Thin coat of spray foam to seal and insulate for "flash and batt"
      • Sealing attic baffles
      • Post mold remediation sealing
      • Mobile home skirt sealing
      • Sealing can lights
      • Sealing ductwork joints
      • Insulating & sealing rim/band joists
      • Insulating crawl space wall
      • Insulating cathedral ceilings
  • Sealants
    • Residential
      • Air sealing attic
      • Sealing can lights
    • Commercial & Industrial
      • Sealing silos and storage bins
      • Retrofitting windows
View All Markets & Solutions >>


Use our Yield Calculator to determine how much low pressure polyurethane foam you need to complete your next project.

*Yields are based on theoretical calculations, for comparison purposes, and will vary depending on ambient conditions and particular application. Other two-component foam product yields are shown on the specific Technical Data Sheet. These examples are representative of other products of similar size.
